Single Point Pneumatic Welding Machine for Cylinder Cell Assembling GN-330A

FOB Reference Price:Get Latest Price
US $1,100-2,000 / Sets | 1 Set/Sets Cylinder cell welding machine (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Other
Place of Origin:
Shandong, China (Mainland)
Brand Name:
Gelon
Model Number:
GN-330A
Voltage:
220-240V
Current:
0-99A
Rated Capacity:
10 Kw
Rated Duty Cycle:
60%
Dimensions:
30.5cm(L) x 50.5cm(W) x 49cm(H)
Weight:
45kg
Usage:
Welding Machine
Certification:
CE
After-sales Service Provided:
Engineers available to service machinery overseas
Air Pressure Range:
0.1 - 0.8 MPa
Welding Current:
0-99A
Welding Thickness:
0.03 - 0.25mm
Operation Temperature:
-20 - 40℃
Warranty:
1 Year
Welding needle:
90mm
Supply 1:
Lithium ion battery materials
Supply 2:
Lithium ion battery machine
Supply 3:
Thermal battery materials
Product name:
Cylinder cell welding machine
Supply Ability
Supply Ability:
1000000 Set/Sets per Month Cylinder cell welding machine
Packaging & Delivery
Packaging Details
Export standard package of Cylinder cell welding machine
Port
Qingdao
Lead Time :
Within 30 working days after payment

Single Point Pneumatic Welding Machine for Cylinder Cell Assembling  GN-330A



GN-330A Precise Pneumatic Single Point Welding Machine is specifically designed for professional Li-on Battery Research. It is mainly used for welding the cylinder core negative terminal (Nickel tab) to the bottom of the cylinder case. 90mm welding needle can easily insert into the cylinder case and weld the bottom. This machine is controlled by microcontroller,  which is very easy to operate and can provide stable performance.



Specification:

Power Supply

220-240V, Single Phase 50/60Hz

Max. Power

10KW

Air Pressure Range

0.1 - 0.8 MPa ( air compressor is required, pls order at related product

below )

Welding Current

0-99A

Welding Thickness

0.03 - 0.25mm

Operation Temperature

-20 - 40℃

Controller

Controlled by microcontroller,achieve monopulse, dipulse, mutiple-pulse

 welding

Pressure

Pressure applied on the welding needle can be adjusted independently

and easy to operate

Design

Unique Photoelectric switch design

Good appearance, small size and light weight

Welding spot looks beautiful,free spark, stable welding current

Weight

45 kg (100 lbs)

Product Dimensions

30.5cm(L) x 50.5cm(W) x 49cm(H)

Warranty

one year limited with lifetime support
